Slope compensation excavator
Slope compensation excavator

Slope compensation excavator

With the slope compensation excavator, you can also safely navigate mountain cemeteries or cemeteries with sloping ground in general. The excavator can be hydraulically inclined by up to about 15° on one side. Thanks to the freely positionable support feet, the excavator is ready for operation in a matter of minutes and is always securely positioned. The support area of the supporting feet can be made even bigger thanks to its attachment “shoes”. This prevents the excavator from sinking when used on soft ground. Working with the Euro-Multi Excavator is lots of fun thanks to the extremely sensitive remote control. The remote control gives the machine operator access to all of the excavator functions.




Additional equipment

  • Remote control for all excavator functions
  • Hydraulic gauge spacing enlargement 60/90 cm
  • Hydraulic chisel / soil drill
  • 1000 mm excavator arm extension
  • 380 volt electrical drive
  • Infinitely pivoting excavator arm
  • Aluminium ramps
  • Suspension for loading via crane
  • Removable gripper teeth protection
Made in Germany

“Made in Germany” quality
Our excavators are exclusively developed and manufactured in our own workshops by trained specialists in Germany.




Technical specifications

Weight: 1900 kg
Overall length: 3000 mm
Track height: 600-900 mm variable
Overall height: 1950 mm
Overall width (frame): 640 mm
Working arm reach: 5000 mm
Optional pivot range: Infinite
Gripper: With rotary motor, bolt-on teeth and ejector
Engine: Kubota Diesel – 26 PS, 3 cylinder with electrical starter, ignition and water-cooling
Shovel volume: 100 litres
Paint colour: RAL 3002 / 9005

Load diagram

Optional 6.2 m
Lifting capacity in kg at jib working radius in m
